Ivey mount Model RTM60 (Mil) / RT200-MOA

Description

Graduations:
RTM 60 0.50 MIL clicks / Rotation index marked 1-9
RT200-MOA 5.0 MOA click / Rotation index marked 0-50 MOA, with half unit hashmark

Dial Knob:
RTM 60 10 MILS/rev (6 total revolutions)
RT200-MOA 50 MOA/rev (4 total revolutions)

Accuracy:
RTM 60 +/-.050 MIL, +/-150 mm at 3000 meters
RT200-MOA /- 0.2 MOA, +/- 6″ at 3000 yards (dial setting versus true optical angle)
Repeatability:
RTM 60 +/-.025 MIL, +/- 75 mm at 3000 meters (Repeat to Zero 2.5mm or .100″ at 100m)
RT200-MOA +/- 0.1 MOA, +/- 3″ at 3000 yards

Rail attachment: 1913 Mil Spec / Picatinny
Base Rail Length: 140 mm (5.5″) or longer required (10mm Slot Pitch)
Slot Spacing: 100 mm (3.94″) center to center ring pivots
Total Length: 13.0 cm (5.14″ overall, 2.74″ middle spacing, 1.20″ ring length)
Ring Height: 30-35mm (1.85″), 40 mm (2.00″)
Objective Size: Accommodates up to 7.62 cm (3.00″) Actual OD (Nominal list size est. 65mm)

Total weight:
30-35mm 907 gram / 32 oz
40mm 963 gram / 34 oz

Ring Material: 7075-T6 Aluminum Alloy, Black Anodize Coating, Mil A-8625, Type II, Class 2
Sub-Base Mat: 4140 Alloy Steel, Black Nitride (Hard Anti-Corrosive Surface Treatment)
Included: Instructions & Wrench Set for initial assembly

Other features
• Hardened Square Clamp Studs
• Rail Clamp, Heavy 1/2″ Hex Nuts
• Integrated Sub-Base & Lower Ring
• 6X Torx Cap bolts, #8-32
